Sleeps 6
-
4 Slides
-
Rear Bedroom
-
36ft Long
-
31,000 lbs
-
Brighton, Palisades, Saguaro
4369 Floorplan
Specifications
Sleeps | 6 | Slides | 4 |
Length | 35 ft 10 in | Ext Width | 8 ft 6 in |
Ext Height | 12 ft 10 in | Int Height | 6 ft 11 in |
Interior Color | Brighton, Palisades, Saguaro | Exterior Color | Barnet, Camden, Stroud |
Hitch Weight | 10000 lbs | GVWR | 38200 lbs |
Dry Weight | 31000 lbs | Cargo Capacity | 7200 lbs |
Fresh Water Capacity | 105 gals | Grey Water Capacity | 75 gals |
Black Water Capacity | 55 gals | Furnace BTU | 35000 btu |
Generator | 8.0 kW Cummins Onan Diesel Quiet Series | Fuel Type | Diesel |
Engine | Cummins L 8.9 | Chassis | Freightliner XCR |
Horsepower | 380 hp | Fuel Capacity | 100 gals |
Wheelbase | 212 in | Available Beds | King |
Torque | 1150 ft-lb | Refrigerator Type | Norcold with Stainless Steel Front |
Refrigerator Size | 10 cu ft | Convection Cooking | Yes |
Cooktop Burners | 3 | Shower Size | 40" x 30" |
Number of Awnings | 1 | Axle Weight Front | 14200 lbs |
Axle Weight Rear | 24000 lbs | LP Tank Capacity | 32 gals |
Water Heater Capacity | 10 gal | Water Heater Type | Gas/Electric DSI |
AC BTU | 30000 btu | TV Info | LR 50" Samsung LED 4K TV on Televator, BR Samsung LED 4K |
Awning Info | Girard G2000 Power w/Wind Sensor, Remote, and LED Lights | Washer/Dryer Available | Yes |
Gross Combined Weight | 48200 lbs | Shower Type | Standard |
Electrical Service | 50 amp |
Description
Newmar Ventana Class A diesel motorhome 3512 highlights:
- Wardrobe with Mirror Doors
- Full Bath
- Booth Dinette
- Kitchen Pantry
- King Bed Slide Out
You can be sure to have plenty of space in this coach thanks to the four slide outs! Once you park for the night, your crew can relax on the hide-a-bed sofa across from the LED TV on power lift, or play a game at the booth dinette, and both furniture can double as sleeping space at night. While the chef of your group is preparing dinner on the three burner recessed gas cooktop or in the stainless steel convection microwave, you can grab snacks from the pantry and set them out on the dry bar. The full bath will allow everyone space to freshen up each day, and the rear private bedroom will have you feeling right at home. Here, you'll sleep soundly on the king bed, be able to store your clothes in the dual wardrobes, and watch a movie in bed with the bedroom LED TV. There are even two more wardrobes, with one including washer and dryer prep!
Newmar's most flexible coach is found with the Ventana motorhome! The STAR foundation improves strength and durability, as well as a quieter and more stable ride than any other Class A diesel coach. The Freightliner chassis comes standard, or you can choose the optional Spartan chassis. Each model is constructed with gelcoat fiberglass exterior sidewalls and front and rear caps, along with Polar Pak R19 batten insulation in the roof so you can enjoy four seasons of fun. Some of the convenient cockpit features include an Xite dash radio with a Nav-N-Go navigation system, six-way power captain's seats, and the Mobileye lane tracking and lane departure system for added safety. You'll love the luxurious look of the porcelain tile floor and three stylish decor options, and each floorplan includes polished solid surface countertops in the kitchen, bath, and bedroom! The exterior is outfitted with the industry-exclusive Full-Paint Masterpiece Finish, Smart Level hydraulic leveling jacks, Silverstar ultra headlight bulbs, and an optional entertainment center!
Features
Standard Features (2025)
Exterior
Standard
- Full-Paint Masterpiece Finish™ with Diamond Shield Protection on Front Cap
- Convex Exterior Mirrors with Remote Control, Defrost and Turn Signal Indicators
- Chrome Exterior Mirrors
- Entrance Door with Automatic Step
- Rear Hitch for Towing Car
- Assist Handle at Entrance Door
- Mud Flaps
- Rear Protective Tow Guard with Stainless Steel Newmar Letters
- Undercoating
- Smart Level Hydraulic Leveling Jacks with Bluetooth Compatible Touch Pad
- Stainless Steel Exterior Trim Pieces on Front Cap and Grill Area
- Painted Power Baggage Door Locks, Keyless Entrance Door with Touch Pad & Doorbell
Optional
- Chrome Power Baggage Door Locks
- Flag Pole Bracket
- Rear Ladder
- Storage Tray 26 X 91 Non-Power, Location Bay 2
- Storage Tray 32 X 91 Non-Power, Location-Bay 2
- Storage Tray 43 X 56 Non-Power, Location-Bay 3
- Storage Tray 43 X 56 Non-Power, Location-Bay 4
Construction
Standard
- Gelcoated Fiberglass Exterior Sidewalls, Front and Rear Caps
- Aluminum-Frame Sidewalls & Roof Construction, 16" on Center
- 5/8" Foam Insulation Laminated in Sidewalls & Ceiling
- Automatic Mechanical Lock Arms on Slideout Rooms-Scissor Style
- Polar Pak R19 Batten Insulation in Roof
- Fiberglass Roof and Integrated Gutter Rail
- Egress Door with Ladder System
Chassis
Standard
- Aluminum Wheels
- Cruise Control
- Comfort Drive™ Steering With Adjustable Control
- Manual Tilt and Telescope Steering Column with VIP Smart Wheel
- Recessed Fuel Fills with Crossover to Fill from Either Side
- Back-Up Alarm
- Anti-Lock Braking System
- Chassis Battery Disconnect
- V-Ride Drive Axle Suspension on Freightliner Chassis
- Glass Dash Instrument Panel
- Dash Panel Optiview - Freightliner
- Headlights Automatic High Beam
- Mobile Eye Tracking and Lane Departure Warning System
- Steering Wheel Nine Function Switch Pod in Center on Spartan Chassis
- Valid Digital Glare Free Dash on Spartan Chassis
- Freightliner® 380Hp on 35-38’ Floor Plans
- Freightliner® Tag Axle 400Hp on 40-43’ Floor Plans
- Tire Pressure Monitoring on Chassis
Optional
- Spartan 380Hp on 35'-38'’ Floor Plans
- Spartan Tag Axle 400Hp on 40-43’ Floor Plans
- OnGuard Collision Mitigation Adaptive Cruise System with Adjustable Following Distance Control-Freightliner or Spartan
Mechanical and Electrical
Windows, Awnings, & Vents
Standard
- Frameless Double-Pane Tinted Safety-Glass Windows
- Fan-Tastic® Vent with Rain Sensor in Kitchen and Bathroom
- Skylight Above Shower
- Girard G2000 Power Side Awning with Wind Sensor, Remote Control & LED lights
- Slideout Awning Covers
- One Piece Tinted Windshield
Optional
- Carefree Window Awning Pkg of (3), 1-Bedroom, 1-Off Door Side Livingroom, 1-Door Side Livingroom
- Kitchen Window*
- Two Nova Side Awnings
- Bunk Windows*
Air Conditioning & Heating
Standard
- Two-15M Penguin™ Heat Pump Air Conditioners
- Three-15M Penguin Heat Pump Air Conditioner on 43’ Floor Plans
- Propane Gas Furnace with Ducted Heat on 34’-40’ Floor Plans
- Dash Heater and Air Conditioner
- Driver & Passenger Dash Overhead Ventilation System
- Wall Mounted Sensors for Heating and Air Conditioning
Optional
- Electric Radiant Heat Installed Below Main Floor Tile
Electrical
Standard
- 8.0 kW Cummins Onan® Diesel Quiet Series Generator
- 50 Amp Electrical Service with Flexible Cord with Automatic Transfer Switch
- Eight 6-Volt House Batteries
- Battery Disconnect Switch for House Battery
- Automatic Generator Start on Low Battery or Temperature Setting
- 10 Watt Solar Panel to Charge Chassis Battery
- 2800w Modified Sine Inverter
- 12-Volt Auxiliary Receptacle on Dashboard
- Emergency Engine Start Switch
- Engine Block Heater
- Exterior Security Light on Doorside
- Midship Side Turn Signals
- LED Lights Recessed in Ceiling and Underneath Overhead Cabinets
- Lights in Exterior Storage Compartments
- Manually Operated Hold-to-Run Slideout Switch
- Cable TV Connection
- Interior Courtesy Lights
- USB Outlet at Dinette and Bedroom Nightstand
- USB Outlet at Dash for Drive Use
- Wireless Charging Mat Built into Dash for Driver Use
- Wireless Charging Mat Built into Passenger Console
- Spare Fuses in Chassis and House Fuse Panels
- Energy Management System
- Multiplex Monitor System 10.1" in Center of Coach with Interior Lighting and HVAC Controls
- Dimmable/Adjustable Reading Lights at Head of Bed
- 110-Volt Recept in Bed Overhead with Two Pass-Through Ports
- 110-Volt/USB Outlet at Head of Each Bunk Area*
- Power Rewind Reel with 33' Cord*
- Power Rewind Reel with 50' Cord*
- Newmar App
- Dash Radio, Cameras and Monitors to Power-up from both House Batteries Ignition
Optional
- Solar Prep with Six Gauge Wire Ran from the Roof to the House Battery Compartment*
- Four Flexible 110w Solar Panels on Roof
- Transfer Switch with Surge Protector
- Lithium Ion 640 AHR Battery System with Two 3000w Pure Sine Inverters
- Lithium Ion 960 AHR Battery System with Two 3000w Pure Sine Inverters
Plumbing & Bath
Standard
- Demand Water System
- Sewage Holding-Tank Rinse
- Dometic® Macerator Stool*
- Sentrel Acrylic Shower Walls with Glass Door
- Water Filter for Entire Unit
- Exterior Shower
- Auto Fill Water Works Compartment
- Power Water Hose Reel
- Aqua Miser Shower System
Optional
- Fold Down Shower Seat
- Hot Water Line to Generator Area*
Interior
Cabinets & Furniture
Standard
- Sable Maple Hardwood Cabinets-Suede Finish
- Concealed Hinges on Cabinet Doors
- Pullout Pantry Shelves*
- Soft Close Cabinet Drawers
- Drawer Slides Push to Release in Pantry
- Drawers with Full Extension Ball Bearing Guides
- Cooktop Cover Flush, Matching Material
- Polished Solid Surface Countertop in Kitchen with Under Mounted Stainless Steel Sink and Sink Covers
- Polished Solid Surface Countertop in Bathroom and Bedroom
- Desk with One Chair*
- Dinette Booth Williamsburg Convertible*
- Lifts on Bed Top
- Ultrafabric Sofa and Driver/Passenger Seats
- Driver Seat with Vibrator for Mobile Eye System
- Driver/Passenger Seats with Six-Way Power, Power Lumbar and Footrest
- Plush Pillow Top Mattress
- Extended Rotation Concealed Hinge for Washer/Dryer Cabinet Door
- Mesh Cell Phone Holder at Each Bunk Bed*
- Molded Silverware Divider Tray
- Villa Comfort Fit Furniture
Optional
- Morel Glazed Maple Hardwood Cabinets—High Gloss or Suede Finish
- Sable Maple Hardwood Cabinets—High Gloss Finish
- Sedona Glazed Maple Hardwood Cabinets—High Gloss or Suede Finish
- Summit Maple Hardwood Cabinets—High Gloss or Suede Finish
- Two-Tone Summit Maple and Sable Maple Hardwood Cabinets—High Gloss or Suede Finish
- Two-Tone Summit Maple and Sedona Glazed Maple Hardwood Cabinets—High Gloss or Suede Finish
- Two-Tone Summit Maple and Morel Glazed Maple Hardwood Cabinets—High Gloss or Suede Finish
- Mattress Air R5 Radius Corner
- Buffet Dinette with Two Fixed and Two Folding Chairs
- Combination Desk with Buffet Table, Two Fixed and Two Folding Chairs
- Dinette Convertible with Two Fixed and Two Folding Chairs that Face to Window
- Dinette Combination Desk with Free Standing Hidden Leaf Table with Two Fixed and Two Folding Chairs that Face to Window
- Dinette Euro Booth with Two Table Leaves, Removable Table Leg and Two Folding Chairs
- Two Recliners with Lampstand and Reading Lights
- 74" Powered Theater Seating with Reading Lights
- 84" Powered Theater Seating with Reading Lights
- 87" Powered Theater Seating with Reading Lights
- Bunk Beds to Convert to Wardrobe
- Bunk Bed Drop-Down Over Driver and Passenger Seats to Windshield with Bunk Ladder
Appliances
Standard
- Convection Stainless Steel Microwave with Air Fryer Feature
- All Electric, Cooktop Flush Mount Induction
- Air Horns
- 19.7 Cu. Ft. Whirlpool® Refrigerator
- Prep for Two-Piece Washer and Dryer
- Fireplace in Living Area*
- Chinook Dual Loop Heat with continuous hot water
Optional
- Splendide® Two-Piece Stacked Washer and Dryer
- Central Vacuum with Tool Kit
- Dishwasher in a Drawer with Stainless Steel Front Below Cooktop
- Electrical Prep for Freezer without Tray
- Beverage Center Dual Zone
- Fireplace
- LP Cooktop, 22 Gallon LP Tank with Six 6-Volt Batteries
Interior
Standard
- Designer Feature Ceiling
- Tile Floor in Kitchen, Bathroom and Living Areas
- Carpeting on Slideout Floors
- MCD Window Shades
- MCD Power Shades at Windshield and Manual Shades on Driver/Passenger Side Windows
- Dash Panel Color Coordinated ABS
- Decorative Wall Art
- Inlayed Three Panel Design Interior Passage Doors
- Interior Assist Handle at Main Entry Door
- Power Stepwell Cover
- Fitted with Round Corner Non-Quilted Bedspread with Accent Pillows
- Removable Transport Pads for Under Slideout Rollers
- Wastebasket in Kitchen Base Under Sink
Optional
- Safe Located in Bedroom Wardrobe
Entertainment
Audio & Video
Standard
- Samsung® LED 4K TV in Living and Bedroom Areas* (TV Sizes Vary Per Floor Plan)
- 50" Samsung® LED 4K TV on Televator in Living Area*
- Dash Radio with Harman/JBL 180w Sound System and Subwoofer
- Xite Dash Radio with Apple CarPlay®, 9" Dual Monitors with Nav-N-Go Navigation System
- Bose® Soundbar Sound System
- Bluetooth Microphone for Dash Radio
- Rear-View Color Monitor System with Audio
- Side-View Cameras Displayed on Rear-View Monitor Screen
- Winegard Digital Crank-up TV Antenna
- Satellite Dish Prep on Roof
- Two Bedroom Radio Speakers
- TV Jack and 110-Volt Recept in Door Side Exterior Storage Compartment
- High-Definition Component Wiring
- 10 Bc Fire Extinguisher, Smoke Detectors, Propane and Carbon Monoxide Detector
Optional
- SiriusXM® Satellite Capability with Antenna (Does not include monthly subscription)*
- 43" Samsung® 4K LED TV in Front Overhead
- Exterior Entertainment Center in Sidewall with 32" Samsung® 4K LED TV and Bose® Soundbar
- Exterior Entertainment Center in Sidewall with 43" Samsung® 4K LED TV and Bose® Soundbar
- Exterior Entertainment Center in Storage Compartment with 43" Samsung® LED TV and Bose® Soundbar
- Xite HD 360 Camera System*
- Extra Monitor on Passenger Side
- Starlink Internet System
- Universal Remote Control
- Universal Toll Module
- Prep for Ground Tripod Satellite Dish on Off Door Side with A/B Switch
- Two 19" Skyworth Monitors at Each Bunk*
- WiFiRanger Denali/Spruce LTE
- WiFi System Everest with Aspen Interior Router
- Winegard Automatic Dome Satellite Dish-for Std/HD, DIRECTV Std and Bell Canada
- Winegard Automatic Open Face Satellite Dish-for HD and Bell HD TV
- Winegard Automatic Open Face SWM Satellite Dish-for DIRECTV Std/HD
- Winegard In-Motion Dome Satellite Dish-for Std/HD, DIRECTV Std and Bell Canada
- Winegard Rayzar Automatic Digital TV Antenna
*Check with dealership on floorplan availability
See us for a complete list of features and available options!
All standard features and specifications are subject to change.
All warranty info is typically reserved for new units and is subject to specific terms and conditions. See us for more details.
Due to the current environment, our features and options are subject to change due to material availability.
Save your favorite RVs as you browse. Begin with this one!
-
Awesome place with awesome service!
Everyone at Dylan's RV Center were very helpful, informative, and friendly. They made you feel right at home and help as much as they can with any questions or concerns you may have. Our new RV is beautiful and in perfect shape and we cannot wait to take it on lots of trips in the future! An overall -
Relationship Builder
Our salesman, Mark Major, went above and beyond to ensure that we understood the coaches we were comparing and I have no doubt that we will have a long and lasting relationship with Mark and Dylans. -
Thank You
Oh my, we are SO grateful for Dylan's RV Service department!!!! After an extremely horrible experience with another RV service business in South Jersey, we were very hesitant to trust anyone. My hubby came across Dylan's. We have had them do several repairs on our rig and are VERY happy and satisfied
Loading
Dylan's RV Center is not responsible for any misprints, typos, or errors found in our website pages. Any price listed excludes sales tax, registration tags, and delivery fees. Manufacturer pictures, specifications, and features may be used in place of actual units on our lot. Please contact us @856-228-0090 for availability as our inventory changes rapidly. All calculated payments are an estimate only and do not constitute a commitment that financing or a specific interest rate or term is available.
Manufacturer and/or stock photographs may be used and may not be representative of the particular unit being viewed. Where an image has a stock image indicator, please confirm specific unit details with your dealer representative.
